36.2.65 Transmit Buffer Transmit Abort Status Register (TMTASTS)
TMTASTSp Flag (RSCAN0 Transmit Buffer p Transmit Abort Status Flag) (p = 0 to 3)
When the TMSTSp.TMTRF[1:0] flags become 01b (transmit abort has been completed), the corresponding TMTASTSp
flag becomes 1.
This flag becomes 0 when the corresponding TMSTSp.TMTRF[1:0] flags are set to 00b or in channel reset mode.
Address(es): RSCAN0.TMTASTS 000A 8378h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
————————————
TMTAS
TS3
TMTAS
TS2
TMTAS
TS1
TMTAS
TS0
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 TMTASTS0 RSCAN0 Transmit Buffer 0
Transmit Abort Status Flag
0: Transmission is not aborted.
1: Transmission is aborted.
R
b1 TMTASTS1 RSCAN0 Transmit Buffer 1
Transmit Abort Status Flag
R
b2 TMTASTS2 RSCAN0 Transmit Buffer 2
Transmit Abort Status Flag
R
b3 TMTASTS3 RSCAN0 Transmit Buffer 3
Transmit Abort Status Flag
R
b15 to b4 — Reserved These bits are read as 0. R
