RX23W Group 26. 8-Bit Timer (TMR)

26.6 Interrupt Sources

26.6.1 Interrupt Sources and DTC Activation

There are three interrupt sources for TMRn: CMIAn, CMIBn, and OVIn. Their interrupt sources and priorities are listed

Table 26.6.

It is also possible to activate the DTC by means of CMIAn and CMIBn interrupts.

Table 26.6 TMR Interrupt Sources

Name Interrupt Sources DTC Activation Priority

CMIA0 TMR0.TCORA compare match Possible High

CMIB0 TMR0.TCORB compare match Possible

OVI0 TMR0.TCNT overflow Not possible

CMIA1 TMR1.TCORA compare match Possible

CMIB1 TMR1.TCORB compare match Possible

OVI1 TMR1.TCNT overflow Not possible

CMIA2 TMR2.TCORA compare match Possible

CMIB2 TMR2.TCORB compare match Possible

OVI2 TMR2.TCNT overflow Not possible

CMIA3 TMR3.TCORA compare match Possible

CMIB3 TMR3.TCORB compare match Possible

OVI3 TMR3.TCNT overflow Not possible Low
