RX23W Group 32. USB 2.0 Host/Function Module (USBc)
32.2.5 CFIFO Port Select Register (CFIFOSEL)
D0FIFO Port Select Register (D0FIFOSEL)
D1FIFO Port Select Register (D1FIFOSEL)
 CFIFOSEL
Note 1. Only 0 can be read.
The same pipe should not be specified by the CURPIPE[3:0] bits in the CFIFOSEL, D0FIFOSEL, and D1FIFOSEL
registers. When the CURPIPE[3:0] bits in the D0FIFOSEL and D1FIFOSEL registers are set to 0000b, no pipe is
selected.
The pipe number should not be changed while the DMA/DTC transfer is enabled.
Address(es): 000A 0020h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
RCNT REW — — — MBW —
BIGEN
D
— — ISEL — CURPIPE[3:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b3 to b0 CURPIPE
[3:0]
CFIFO Port Access Pipe Specification
b3 b0
0 0 0 0: DCP (Default control pipe)
0 0 0 1: Pipe 1
0 0 1 0: Pipe 2
0 0 1 1: Pipe 3
0 1 0 0: Pipe 4
0 1 0 1: Pipe 5
0 1 1 0: Pipe 6
0 1 1 1: Pipe 7
1 0 0 0: Pipe 8
1 0 0 1: Pipe 9
Settings other than above are prohibited.
R/W
b4 — Reserved This bit is read as 0. The write value should be 0. R/W
b5 ISEL CFIFO Port Access Direction When
DCP is Selected
0: Reading from the buffer memory is selected.
1: Writing to the buffer memory is selected.
R/W
b7, b6 — Reserved These bits are read as 0. The write value should be 0. R/W
b8 BIGEND CFIFO Port Endian Control 0: Little endian
1: Big endian
R/W
b9 — Reserved This bit is read as 0. The write value should be 0. R/W
b10 MBW CFIFO Port Access Bit Width 0: 8-bit width
1: 16-bit width
R/W
b13 to b11 — Reserved These bits are read as 0. The write value should be 0. R/W
b14 REW Buffer Pointer Rewind 0: The buffer pointer is not rewound.
1: The buffer pointer is rewound.
R/W
*1
b15 RCNT Read Count Mode 0: The DTLN[8:0] flags (CFIFOCTR.DTLN[8:0],
D0FIFOCTR.DTLN[8:0], D1FIFOCTR.DTLN[8:0]) are
cleared when all of the receive data has been read from
the CFIFO.
(In double buffer mode, the DTLN[8:0] bit value is
cleared when all the data has been read from only a
single plane.)
1: The DTLN[8:0] flags are decremented each time the
receive data is read from the CFIFO.
R/W
