RX23W Group 40. SD Host Interface (SDHIa)

40.3.6.7 IO_RW_DIRECT Command (CMD52)

Figure 40.14 shows an example of issuing the IO_RW_DIRECT command (CMD52).

Figure 40.14 Issuing the IO_RW_DIRECT Command

Clear the flag register

Set the SDCLKCR register.

SDIMSK1 = 0000 FFFEh

SDIMSK2 = 0000 7F80h

SDIOMD = 0000 0001h

SDIOIMSK = 0000 FFFEh

Did a response end

or error occur?

SDSTS1 = 0000 FFFEh Clear the flags.

SDARG = Argument field value

SDCMD = 0000 0034h

CMD52 (IO_RW_DIRECT

command) issued

Error (communication error or timeout)

Read the SDRSP10 register Check the response.

Error processing

(clear the interrupt flags)

Yes

Start

End
