RX23W Group 50. Flash Memory (FLASH)
50.10.8.4 Erase Preparation
This command is used to prepare for accepting the block erase command. When the MCU receives this command, it
recognizes that an instruction to prepare for the erase command is issued from the host. Then, the MCU enters the erase
wait state, where only the block erase command can be accepted, and sends a response (06h).
50.10.8.5 Block Erase
This command is used to erase the selected block in the user area or data area. Specify the block start address selected in
the command by calculating the address based on the response to the block information inquiry command.
When the block selected in the block start address is successfully erased, the MCU sends an error response (06h). If the
SUM of the received command does not match or an error occurs during an erase operation, the MCU sends an error
response.
To enter the program/erase host command wait state after the erase operation ends, send 59h 04h FFh FFh FFh FFh A7h
from the host. The MCU enters the program/erase host command wait state and sends a response (06h).
Size (1 byte): Total bytes of Block start address (the value is always 04h)
Block start address (4 bytes): Start address of the block that is erased
Set FFFF FFFFh for end of erase
SUM (1 byte): Value that is calculated so the sum of response data is 00h
Error (1 byte): Error code
11h: SUM error
29h: Block start address error
51h: Erase error (the selected block cannot be erased)
Command 48h
Response 06h
Command 59h Size
Block start address
Response SUM
Response 06h
Error response D9h Error
