R01UH0823EJ0100 Rev.1.00 Page 1817 of 1823
Jul 31, 2019
RX23W Group Appendix 1. Port States in Each Processing Mode
Appendix 1. Port States in Each Processing Mode
Keep-O: Output pins retain their previous values, and input pins become high-impedance.
Hi-Z: High-impedance
Note 1. Input is enabled if the pin is specified as the software standby mode canceling source while it is used as an external interrupt pin.
Note 2. Input is enabled if the pin is used a USB pin (USB0_VBUS/USB0_OVRCURA/USB0_OVRCURB).
Table 1.1 Port States in Each Processing Mode
Port Name
(Pin Name) Operating Mode According to Registers Setting Reset
Software Standby Mode
OPE = 1 OPE = 0
P03
(DA0)
All DA0 output
(DAOE0 = 1)
Hi-Z DA output retained
Other than the above
(DAOE0 = 0)
Keep-O
P05
(DA1)
All DA1 output
(DAOE1 = 1)
Hi-Z DA output retained
Other than the above
(DAOE1 = 0)
Keep-O
P07 All Hi-Z Keep-O
P14
(USB0_OVRCURA/
IRQ4)
All Hi-Z Keep-O*
1,
*
2
P15
(IRQ5)
All Hi-Z Keep-O*
1
P16
(USB0_VBUS/
USB0_OVRCURB/
IRQ6/RTCOUT)
All Hi-Z [RTCOUT output]
RTCOUT output
[Other than the above]
Keep-O*
1,
*
2
P17
(CMPOB2/IRQ7)
All Hi-Z [CMPOB2 output]
CMPOB2 output
[Other than the above]
Keep-O*
1
P21 All Hi-Z Keep-O
P22
(USB0_OVRCURB)
All Hi-Z Keep-O*
2
P25 to P27 All Hi-Z Keep-O
P30
(CMPOB3/IRQ0)
All Hi-Z [CMPOB3 output]
CMPOB3 output
[Other than the above]
Keep-O*
1
P31
(IRQ1)
All Hi-Z Keep-O*
1
P35
(NMI)
All Hi-Z Keep-O*
1
P36, P37 All Hi-Z Keep-O
P40 to P47 All Hi-Z Keep-O
PB0 All Hi-Z Keep-O
PB1
(IRQ4)
All Hi-Z Keep-O*
1
PB3 All Hi-Z Keep-O
PB5
(USB0_VBUS)
All Hi-Z Keep-O*
2
PB7 All Hi-Z Keep-O
PC0, PC2 to PC7 All Hi-Z Keep-O
PD3 All Hi-Z Keep-O
PE0, PE1 All Hi-Z Keep-O
PE2
(IRQ7)
All Hi-Z Keep-O*
1
PE3, PE4
(CLKOUT, CLKOUT)
All Hi-Z [CLKOUT output]
CLKOUT output
[Other than the above]
Keep-O
PJ3 All Hi-Z Keep-O
To Next Page
