RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)
23.3.7 Reset-Synchronized PWM Mode
In the reset-synchronized PWM mode, six phases of positive and negative PWM waveforms that share a common wave
transition point can be output by combining MTU3 and MTU4.
When set for reset-synchronized PWM mode, the MTIOC3B, MTIOC3D, MTIOC4A, MTIOC4C, MTIOC4B, and
MTIOC4D pins function as PWM output pins and the MTU3.TCNT counter functions as an up-counter.
Table 23.49 lists the PWM output pins. Table 23.50 lists the settings of the registers.
Table 23.49 Output Pins for Reset-Synchronized PWM Mode
Channel Output Pin Description
MTU3 MTIOC3B PWM output pin 1
MTIOC3D PWM output pin 1’ (negative-phase waveform of PWM output 1)
MTU4 MTIOC4A PWM output pin 2
MTIOC4C PWM output pin 2’ (negative-phase waveform of PWM output 2)
MTIOC4B PWM output pin 3
MTIOC4D PWM output pin 3’ (negative-phase waveform of PWM output 3)
Table 23.50 Register Settings for Reset-Synchronized PWM Mode
Register Setting
MTU3.TCNT Initial setting (0000h)
MTU4.TCNT Initial setting (0000h)
MTU3.TGRA Set the count cycle for MTU3.TCNT
MTU3.TGRB Set the transition point of the PWM waveform to be output from the MTIOC3B and MTIOC3D pins
MTU4.TGRA Set the transition point of the PWM waveform to be output from the MTIOC4A and MTIOC4C pins
MTU4.TGRB Set the transition point of the PWM waveform to be output from the MTIOC4B and MTIOC4D pins
