R01UH0823EJ0100 Rev.1.00 Page 648 of 1823

Jul 31, 2019

RX23W Group 24. Port Output Enable 2 (POE2a)

24.2.5 Port Output Enable Control Register 1 (POECR1)

Note 1. Can be modified only once after a reset.

Address(es): 0008 890Bh

b7 b6 b5 b4 b3 b2 b1 b0

—————PE2ZEPE1ZEPE0ZE

Value after reset:

00000000

Bit Symbol Bit Name Description R/W

b0 PE0ZE MTIOC0A High-Impedance

Enable

0: Does not place the pin in high-impedance.

1: Places the pin in high-impedance.

R/W*

b1 PE1ZE MTIOC0B High-Impedance

Enable

0: Does not place the pin in high-impedance.

1: Places the pin in high-impedance.

R/W*

b2 PE2ZE MTIOC0C High-Impedance

Enable

0: Does not place the pin in high-impedance.

1: Places the pin in high-impedance.

R/W*

b7 to b3 — Reserved These bits are read as 0. The write value should be 0. R/W
