RX23W Group 26. 8-Bit Timer (TMR)
26.2.5 Timer Counter Control Register (TCCR)
Note 1. To use an external count clock, set the corresponding pin function. For details, refer to section 21, I/O Ports and section 22,
Multi-Function Pin Controller (MPC).
Note 2. This bit is reserved in TMR0. The bit is read as 0. Writing to these bits is not possible.
TCCR register is a 8-bit register used to configure the basic operation of the counter. Two TCCR registers can be
accessed simultaneously by accessing the address of the even channel TCCR register in 16-bit units.
CKS[2:0] Bits (Clock Select)
CSS[1:0] Bits (Clock Source Select)
The CKS[2:0] and CSS[1:0] bits select a clock. For details, see
Table 26.5.
TMRIS Bit (Timer Reset Detection Condition Select)
This bit is enabled when the TCR.CCLR[1:0] bits are 11b (cleared by external counter reset signal) and selects the
condition for detecting counter reset (level or edge).
Address(es): TMR0.TCCR 0008 820Ah, TMR1.TCCR 0008 820Bh, TMR2.TCCR 0008 821Ah, TMR3.TCCR 0008 821Bh,
TMR01.TCCR 0008 820Ah, TMR23.TCCR 0008 821Ah
b7 b6 b5 b4 b3 b2 b1 b0
TMRIS — — CSS[1:0] CKS[2:0]
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b2 to b0 CKS[2:0] Clock Select*
1
See Table 26.5. R/W
b4, b3 CSS[1:0] Clock Source Select See Table 26.5. R/W
b6, b5 — Reserved These bits are read as 0. The write value should be 0. R/W
b7 TMRIS Timer Reset Detection Condition
Select*
2
0: Cleared at rising edge of the external counter reset
signal
1: Cleared when the external counter reset signal is high
R/W
To Next Page
