R01UH0823EJ0100 Rev.1.00 Page 417 of 1823
Jul 31, 2019
RX23W Group 20. Event Link Controller (ELC)
20.2.7 Port Group Setting Register n (PGRn) (n = 1, 2)
The PGRn register specifies a group of I/O ports. Among the ports, ports corresponding to bits set to 1 in the register are
selected for a port group.
For example, when the PGR6 and PGR3 bits in the PGR1 register are set to 1, the PB6 and PB3 pins are selected to a port
group.
Table 20.4 shows the PGRn register and corresponding ports.
Address(es): ELC.PGR1 0008 B123h, ELC.PGR2 0008 B124h
b7 b6 b5 b4 b3 b2 b1 b0
PGR7 PGR6 PGR5 PGR4 PGR3 PGR2 PGR1 PGR0
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 PGR0 Port Group Setting 0 0: Does not specify the port as a member of the port group.
1: Specifies the port as a member of the port group.
R/W
b1 PGR1 Port Group Setting 1 R/W
b2 PGR2 Port Group Setting 2 R/W
b3 PGR3 Port Group Setting 3 R/W
b4 PGR4 Port Group Setting 4 R/W
b5 PGR5 Port Group Setting 5 R/W
b6 PGR6 Port Group Setting 6 R/W
b7 PGR7 Port Group Setting 7 R/W
Table 20.4 Registers Related to Port Groups and Corresponding Port Numbers
Port Number Port Group Setting Register (PGR) Port Group Control Register (PGC) Port Buffer Register (PDBF)
Port B PGR1 register PGC1 register PDBF1 register
Port E PGR2 register PGC2 register PDBF2 register
