RX23W Group 32. USB 2.0 Host/Function Module (USBc)
32.2.10 NRDY Interrupt Enable Register (NRDYENB)
The NRDYENB register enables or disables the INTSTS0.NRDY flag to be set to 1 when the NRDY interrupt is
detected for each pipe.
On detecting the NRDY interrupt for the pipe corresponding to the bit in the NRDYENB register to which 1 has been set
by software, the USB sets 1 to the corresponding NRDYSTS.PIPEnNRDY flag (n = 0 to 9) and the INTSTS0.NRDY
flag. If INTENB0.NRDYE = 1 at this time, the USB generates the NRDY interrupt request.
While at least one PIPEnNRDY flag indicates 1, the USB generates the NRDY interrupt request when the corresponding
interrupt enable bit in the NRDYENB register is modified from 0 to 1 by software.
Address(es): 000A 0038h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
——————
PIPE9N
RDYE
PIPE8N
RDYE
PIPE7N
RDYE
PIPE6N
RDYE
PIPE5N
RDYE
PIPE4N
RDYE
PIPE3N
RDYE
PIPE2N
RDYE
PIPE1N
RDYE
PIPE0N
RDYE
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 PIPE0NRDYE NRDY Interrupt Enable for PIPE0 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b1 PIPE1NRDYE NRDY Interrupt Enable for PIPE1 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b2 PIPE2NRDYE NRDY Interrupt Enable for PIPE2 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b3 PIPE3NRDYE NRDY Interrupt Enable for PIPE3 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b4 PIPE4NRDYE NRDY Interrupt Enable for PIPE4 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b5 PIPE5NRDYE NRDY Interrupt Enable for PIPE5 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b6 PIPE6NRDYE NRDY Interrupt Enable for PIPE6 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b7 PIPE7NRDYE NRDY Interrupt Enable for PIPE7 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b8 PIPE8NRDYE NRDY Interrupt Enable for PIPE8 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b9 PIPE9NRDYE NRDY Interrupt Enable for PIPE9 0: Interrupt output disabled
1: Interrupt output enabled
R/W
b15 to b10 — Reserved These bits are read as 0. The write value should be 0. R/W
