RX23W Group 36. CAN Module (RSCAN)
36.2.68 Transmit Buffer Register pAH (TMIDHp) (p = 0 to 3)
Modify this register when the corresponding TMSTSp.TMTRM flag is 0 (no transmit request is present). If this register
is linked to any transmit/receive FIFO buffer, do not write data to this register.
This register can be read/written when the GRWCR.RPAGE bit is 1.
TMID[28:16] Bits (Transmit Buffer ID Data H)
These bits are used to set the ID of the message to be transmitted from the transmit buffer.
THLEN Bit (Transmit History Data Store Enable)
When this bit is set to 1, the transmit history data (label information, buffer number, and buffer type) of transmit
messages is stored in the transmit history buffer after transmission is completed.
TMRTR Bit (Transmit Buffer RTR)
This bit is used to set the data format of the message to be transmitted from the transmit buffer.
TMIDE Bit (Transmit Buffer IDE)
This bit is used to set the ID format of the message to be transmitted from the transmit buffer.
Address(es): RSCAN0.TMIDH0 000A 8602h, RSCAN0.TMIDH1 000A 8612h, RSCAN0.TMIDH2 000A 8622h,
RSCAN0.TMIDH3 000A 8632h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
TMIDE TMRTR THLEN TMID[28:16]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b12 to b0 TMID[28:16] Transmit Buffer ID Data H Set standard ID or extended ID.
For standard ID, write 0 to these bits.
R/W
b13 THLEN Transmit History Data Store
Enable
0: Transmit history data is not stored in the buffer.
1: Transmit history data is stored in the buffer.
R/W
b14 TMRTR Transmit Buffer RTR 0: Data frame
1: Remote frame
R/W
b15 TMIDE Transmit Buffer IDE 0: Standard ID
1: Extended ID
R/W
