R01UH0823EJ0100 Rev.1.00 Page 1571 of 1823
Jul 31, 2019
RX23W Group 44. 12-Bit A/D Converter (S12ADE)
44.2.28 A/D Compare Function Window A Channel Status Register 1 (ADCMPSR1)
The ADCMPSR1 register stores the comparison results of the compare window A function.
CMPSTCHA1n Flag (n = 00 to 04, 11) (Compare Window A Flag)
This flag is comparison result status flag of channel (AN016 to AN020, AN027) to which window A comparison
conditions are applied. When the comparison condition set by ADCMPLR1.CMPLCHA1n is met at the end of A/D
conversion, each of these flags is set to 1. The
CMPSTCHA100
bit corresponds to AN016, the
CMPSTCHA104
bit
corresponds to AN020, and the
CMPSTCHA111
bit corresponds to AN027.
Writing 1 to the CMPSTCHA1n flag (n = 00 to 04, 11) is disabled.
[Setting condition]
The condition set by ADCMPLR1.CMPLCHA1n is met when ADCMPCR.CMPAE = 1
[Clearing condition]
0 is written after reading 1
Address(es): S12AD.ADCMPSR1 0008 90A2h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
————
CMPST
CHA111
——————
CMPST
CHA104
CMPST
CHA103
CMPST
CHA102
CMPST
CHA101
CMPST
CHA100
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0
CMPSTCHA100
Compare Window A Flag When window A operation is enabled (ADCMPCR.CMPAE = 1),
these flags indicate the comparison result of channels (AN016
to AN020) to which window A comparison conditions are
applied.
0: Comparison conditions are not met.
1: Comparison conditions are met.
R/W
b1
CMPSTCHA101
R/W
b2
CMPSTCHA102
R/W
b3
CMPSTCHA103
R/W
b4
CMPSTCHA104
R/W
b10 to b5 — Reserved These bits are read as 0. The write value should be 0. R/W
b11
CMPSTCHA111
Compare Window A Flag When window A operation is enabled (ADCMPCR.CMPAE = 1),
this flag indicates the comparison result of channel (AN027) to
which window A comparison condition is applied.
0: Comparison conditions are not met.
1: Comparison conditions are met.
R/W
b15 to b12 — Reserved These bits are read as 0. The write value should be 0. R/W
