R01UH0823EJ0100 Rev.1.00 Page 82 of 1823

Jul 31, 2019

RX23W Group 2. CPU

2.4.4 Strings

The string data type consists of an arbitrary number of consecutive byte (8-bit), word (16-bit), or longword (32-bit) units.

Seven string manipulation instructions are provided for use with strings: SCMPU, SMOVB, SMOVF, SMOVU, SSTR,

SUNTIL, and SWHILE.

Figure 2.5 String

String of byte (8-bit) data

String of word (16-bit) data

String of longword (32-bit) data
