R01UH0823EJ0100 Rev.1.00 Page 515 of 1823
Jul 31, 2019
RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)
23.2.28 Timer Dead Time Enable Registers (TDER)
Note 1. TDDR must be set to 1 or a larger value.
The TDER register specifies dead time generation in complementary PWM mode. The MTU3 has one TDER register.
The TDER register should be modified only while the TCNT counter stops.
TDER Bit (Dead Time Enable)
This bit specifies whether to generate dead time.
[Clearing condition]
ï‚· When 0 is written to the TDER bit after reading the TDER bit = 1
Address(es): MTU.TDER 000D 0A34h
b7 b6 b5 b4 b3 b2 b1 b0
———————TDER
Value after reset:
00000001
Bit Symbol Bit Name Description R/W
b0 TDER Dead Time Enable 0: No dead time is generated
1: Dead time is generated*
1
R/(W)
b7 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
