R01UH0823EJ0100 Rev.1.00 Page 1014 of 1823
Jul 31, 2019
RX23W Group 33. Serial Communications Interface (SCIg, SCIh)
33.2.30 Control Field 0 Compare Enable Register (CF0CR)
33.2.31 Control Field 0 Receive Data Register (CF0RR)
CF0RR is a readable register that holds the value received in Control Field 0.
33.2.32 Primary Control Field 1 Data Register (PCF1DR)
PCF1DR is an 8-bit readable and writable register that holds the 8-bit primary value for comparison with Control Field 1.
Address(es): SCI12.CF0CR 0008 B32Ah
b7 b6 b5 b4 b3 b2 b1 b0
CF0CE
7
CF0CE
6
CF0CE
5
CF0CE
4
CF0CE
3
CF0CE
2
CF0CE
1
CF0CE
0
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 CF0CE0 Control Field 0 Bit 0 Compare Enable 0: Comparison with bit 0 of Control Field 0 is disabled.
1: Comparison with bit 0 of Control Field 0 is enabled.
R/W
b1 CF0CE1 Control Field 0 Bit 1 Compare Enable 0: Comparison with bit 1 of Control Field 0 is disabled.
1: Comparison with bit 1 of Control Field 0 is enabled.
R/W
b2 CF0CE2 Control Field 0 Bit 2 Compare Enable 0: Comparison with bit 2 of Control Field 0 is disabled.
1: Comparison with bit 2 of Control Field 0 is enabled.
R/W
b3 CF0CE3 Control Field 0 Bit 3 Compare Enable 0: Comparison with bit 3 of Control Field 0 is disabled.
1: Comparison with bit 3 of Control Field 0 is enabled.
R/W
b4 CF0CE4 Control Field 0 Bit 4 Compare Enable 0: Comparison with bit 4 of Control Field 0 is disabled.
1: Comparison with bit 4 of Control Field 0 is enabled.
R/W
b5 CF0CE5 Control Field 0 Bit 5 Compare Enable 0: Comparison with bit 5 of Control Field 0 is disabled.
1: Comparison with bit 5 of Control Field 0 is enabled.
R/W
b6 CF0CE6 Control Field 0 Bit 6 Compare Enable 0: Comparison with bit 6 of Control Field 0 is disabled.
1: Comparison with bit 6 of Control Field 0 is enabled.
R/W
b7 CF0CE7 Control Field 0 Bit 7 Compare Enable 0: Comparison with bit 7 of Control Field 0 is disabled.
1: Comparison with bit 7 of Control Field 0 is enabled.
R/W
Address(es): SCI12.CF0RR 0008 B32Bh
b7 b6 b5 b4 b3 b2 b1 b0
Value after reset:
00000000
Address(es): SCI12.PCF1DR 0008 B32Ch
b7 b6 b5 b4 b3 b2 b1 b0
Value after reset:
00000000
