R01UH0823EJ0100 Rev.1.00 Page 1218 of 1823
Jul 31, 2019
RX23W Group 36. CAN Module (RSCAN)
36.2.26 Receive Buffer Register nAL (RMIDLn) (n = 0 to 15)
This register can be read when the GRWCR.RPAGE bit is 1.
RMID[15:0] Bits (Receive Buffer ID Data L)
These bits indicate the ID of the message stored in the receive buffer.
Address(es): RSCAN.RMIDL0 000A 83A0h, RSCAN.RMIDL1 000A 83B0h, RSCAN.RMIDL2 000A 83C0h,
RSCAN.RMIDL3 000A 83D0h, RSCAN.RMIDL4 000A 83E0h, RSCAN.RMIDL5 000A 83F0h,
RSCAN.RMIDL6 000A 8400h, RSCAN.RMIDL7 000A 8410h, RSCAN.RMIDL8 000A 8420h,
RSCAN.RMIDL9 000A 8430h, RSCAN.RMIDL10 000A 8440h, RSCAN.RMIDL11 000A 8450h,
RSCAN.RMIDL12 000A 8460h, RSCAN.RMIDL13 000A 8470h, RSCAN.RMIDL14 000A 8480h,
RSCAN.RMIDL15 000A 8490h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
RMID[15:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b15 to b0 RMID[15:0] Receive Buffer ID Data L The standard ID or extended ID of received message can be
read.
Read bits 10 to 0 for standard ID. Bits 15 to 11 are read as 0.
R
