RX23W Group 2. CPU

2.4 Data Types

The RXv2 CPU can handle four types of data: integer, floating-point, bit, and string.

For details, refer to RX Family RXv2 Instruction Set Architecture User's Manual: Software.

2.4.1 Integer

An integer can be signed or unsigned. For signed integers, negative values are represented by two's complements.

Figure 2.2 Integer

Unsigned longword (32-bit) integer

Signed longword (32-bit) integer

Unsigned word (16-bit) integer

Signed word (16-bit) integer

Unsigned byte (8-bit) integer

Signed byte (8-bit) integer

S: Signed bit

b31 b0

b15 b0

b7 b0
