R01UH0823EJ0100 Rev.1.00 Page 468 of 1823

Jul 31, 2019

RX23W Group 22. Multi-Function Pin Controller (MPC)

22.2.11 PJn Pin Function Control Registers (PJnPFS) (n = 3)

Address(es): PJ3PFS 0008 C1D3h

b7 b6 b5 b4 b3 b2 b1 b0

— — — PSEL[4:0]

Value after reset:

00000000

Bit Symbol Bit Name Description R/W

b4 to b0 PSEL[4:0] Pin Function Select These bits select the peripheral function. For individual pin functions,

see the tables below.

R/W

b7 to b5 — Reserved These bits are read as 0. The write value should be 0. R/W

Table 22.13 Register Settings for Input/Output Pin Function in 85-Pin

PSEL[4:0]

Settings

PJ3

00000b

(initial value)

Hi-Z

00001b MTIOC3C
