R01UH0823EJ0100 Rev.1.00 Page 462 of 1823

Jul 31, 2019

RX23W Group 22. Multi-Function Pin Controller (MPC)

22.2.6 P4n Pin Function Control Registers (P4nPFS) (n = 0 to 7)

Address(es): P40PFS 0008 C160h, P41PFS 0008 C161h, P42PFS 0008 C162h, P43PFS 0008 C163h,

P44PFS 0008 C164h, P45PFS 0008 C165h, P46PFS 0008 C166h, P47PFS 0008 C167h

b7 b6 b5 b4 b3 b2 b1 b0

ASEL———————

Value after reset:

00000000

Bit Symbol Bit Name Description R/W

b6 to b0 — Reserved These bits are read as 0. The write value should be 0. R/W

b7 ASEL Analog Function Select 0: Not used as an analog pin

1: Used as an analog pin

P40: AN000 (85 pins)

P41: AN001 (85/56 pins)

P42: AN002 (85 pins)

P43: AN003 (85 pins)

P44: AN004 (85 pins)

P45: AN005 (85/56 pins)

P46: AN006 (85/56 pins)

P47: AN007 (85/56 pins)

R/W
