RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)
23.2.25 Timer Interrupt Skipping Set Registers (TITCR)
Note 1. When 0 is specified for the interrupt skipping count, no interrupt skipping will be performed.
Before changing the interrupt skipping count, be sure to set the TITCR.T3AEN and TITCR.T4VEN bits to 0 to clear the TITCNT
counter.
Address(es): MTU.TITCR 000D 0A30h
b7 b6 b5 b4 b3 b2 b1 b0
T3AEN T3ACOR[2:0] T4VEN T4VCOR[2:0]
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b2 to b0 T4VCOR[2:0] TCIV4 Interrupt Skipping Count
Setting
These bits specify the TCIV4 interrupt skipping count within
the range from 0 to 7.*
1
For details, refer to Table 23.37.
R/W
b3 T4VEN T4VEN 0: TCIV4 interrupt skipping disabled
1: TCIV4 interrupt skipping enabled
R/W
b6 to b4 T3ACOR[2:0] TGIA3 Interrupt Skipping Count
Setting
These bits specify the TGIA3 interrupt skipping count within
the range from 0 to 7.*
1
For details, refer to Table 23.38.
R/W
b7 T3AEN T3AEN 0: TGIA3 interrupt skipping disabled
1: TGIA3 interrupt skipping enabled
R/W
Table 23.37 Setting of Interrupt Skipping Count by T4VCOR[2:0] Bits
Bit 2 Bit 1 Bit 0
DescriptionT4VCOR[2] T4VCOR[1] T4VCOR[0]
0 0 0 Does not perform TCIV4 interrupt skipping.
0 0 1 Sets the TCIV4 interrupt skipping count to 1.
0 1 0 Sets the TCIV4 interrupt skipping count to 2.
0 1 1 Sets the TCIV4 interrupt skipping count to 3.
1 0 0 Sets the TCIV4 interrupt skipping count to 4.
1 0 1 Sets the TCIV4 interrupt skipping count to 5.
1 1 0 Sets the TCIV4 interrupt skipping count to 6.
1 1 1 Sets the TCIV4 interrupt skipping count to 7.
Table 23.38 Setting of Interrupt Skipping Count by T3ACOR[2:0] Bits
Bit 6 Bit 5 Bit 4
DescriptionT3ACOR[2] T3ACOR[1] T3ACOR[0]
0 0 0 Does not perform TGIA3 interrupt skipping.
0 0 1 Sets the TGIA3 interrupt skipping count to 1.
0 1 0 Sets the TGIA3 interrupt skipping count to 2.
0 1 1 Sets the TGIA3 interrupt skipping count to 3.
1 0 0 Sets the TGIA3 interrupt skipping count to 4.
1 0 1 Sets the TGIA3 interrupt skipping count to 5.
1 1 0 Sets the TGIA3 interrupt skipping count to 6.
1 1 1 Sets the TGIA3 interrupt skipping count to 7.
