RX23W Group 36. CAN Module (RSCAN)
36.2.29 Receive Buffer Register nBH (RMPTRn) (n = 0 to 15)
x: Don’t care
This register can be read when the GRWCR.RPAGE bit is 1.
RMPTR[11:0] Bits (Receive Buffer Label Data)
These bits indicate the label information of the message stored in the receive buffer.
RMDLC[3:0] Bits (Receive Buffer DLC Data)
These bits indicate the data length of the message stored in the receive buffer.
Address(es): RSCAN.RMPTR0 000A 83A6h, RSCAN.RMPTR1 000A 83B6h, RSCAN.RMPTR2 000A 83C6h,
RSCAN.RMPTR3 000A 83D6h, RSCAN.RMPTR4 000A 83E6h, RSCAN.RMPTR5 000A 83F6h,
RSCAN.RMPTR6 000A 8406h, RSCAN.RMPTR7 000A 8416h, RSCAN.RMPTR8 000A 8426h,
RSCAN.RMPTR9 000A 8436h, RSCAN.RMPTR10 000A 8446h, RSCAN.RMPTR11 000A 8456h,
RSCAN.RMPTR12 000A 8466h, RSCAN.RMPTR13 000A 8476h, RSCAN.RMPTR14 000A 8486h,
RSCAN.RMPTR15 000A 8496h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
RMDLC[3:0] RMPTR[11:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b11 to b0 RMPTR[11:0] Receive Buffer Label Data Label information of the received message can be read. R
b15 to b12 RMDLC[3:0] Receive Buffer DLC Data
b15 b12
0000:0 data bytes
0001:1 data byte
0010:2 data bytes
0011:3 data bytes
0100:4 data bytes
0101:5 data bytes
0110:6 data bytes
0111:7 data bytes
1 x x x: 8 data bytes
R
