RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)
23.2.21 Timer Subcounters (TCNTS)
Note: The TCNTS counters must not be accessed in 8-bit units; they should be accessed in 16-bit units.
The TCNTS counters are read-only counters that are used only in complementary PWM mode.
23.2.22 Timer Dead Time Data Registers (TDDR)
Note: The TDDR registers must not be accessed in 8-bit units; they should be accessed in 16-bit units.
The TDDR registers specify the MTU3.TCNT and MTU4.TCNT counter offset value in complementary PWM mode. In
complementary PWM mode, when the MTU3.TCNT and MTU4.TCNT counters are cleared and then restarted, the
TDDR register value is loaded into the MTU3.TCNT counter and the count operation starts.
Table 23.36 Output Level Select Function
Bit 2 Bit 1 Bit 0 Function
WF VF UF
MTIOC3B MTIOC4A MTIOC4B MTIOC3D MTIOC4C MTIOC4D
U Phase V Phase W Phase U Phase V Phase W Phase
0 0 0 OFF OFF OFF OFF OFF OFF
0 0 1 ON OFF OFF OFF OFF ON
0 1 0 OFF ON OFF ON OFF OFF
0 1 1 OFF ON OFF OFF OFF ON
1 0 0 OFF OFF ON OFF ON OFF
1 0 1 ON OFF OFF OFF ON OFF
110OFFOFFONONOFFOFF
1 1 1 OFF OFF OFF OFF OFF OFF
Address(es): MTU.TCNTS 000D 0A20h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Value after reset:
0000000000000000
Address(es): MTU.TDDR 000D 0A16h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Value after reset:
1111111111111111
