RX23W Group 36. CAN Module (RSCAN)
36.2.78 Global RAM Window Control Register (GRWCR)
RPAGE Bit (RAM Window Select)
This bit is used to select a window for the switching of registers that are allocated to addresses from 000A 83A0h to
000A 8681h.
[Registers allocated when the RPAGE bit is set to 0 (window 0 selected)]
 Receive rule entry registers: GAFLIDLj, GAFLIDHj, GAFLMLj, GAFLMHj, GAFLPLj, GAFLPHj (j = 0 to 15)
 RAM test registers: RPGACCr (r = 0 to 127)
[Registers allocated when the RPAGE bit is set to 1 (window 1 selected)]
 Receive buffer registers: RMIDLn, RMIDHn, RMTSn, RMPTRn, RMDF0n to RMDF3n (n = 0 to 15)
 Receive FIFO access registers: RFIDLm, RFIDHm, RFTSm, RFPTRm, RFDF0m to RFDF3m (m = 0, 1)
 Transmit/receive FIFO access registers: CFIDL0, CFIDH0, CFTS0, CFPTR0, CFDF00 to CFDF30
 Transmit buffer registers: TMIDLp, TMIDHp, TMPTRp, TMDF0p to TMDF3p (p = 0 to 3)
 Transmit history buffer access register: THLACC0
Address(es): RSCAN.GRWCR 000A 838Ah
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
———————————————RPAGE
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 RPAGE RAM Window Select 0: Selects window 0 (receive rule entry registers, RAM test
registers)
1: Selects window 1 (receive buffer, receive FIFO buffer,
transmit/receive FIFO buffer, transmit buffer, transmit
history data access register)
R/W
b15 to b1 — Reserved The write value should be 0. R/W
