Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 1565 of 1823
Jul 31, 2019
RX23W Group 44. 12-Bit A/D Converter (S12ADE)
44.2.23 A/D Compare Function Window A Comparison Condition Setting Register 1
(ADCMPLR1)
The ADCMPLR1 register sets the condition for use in comparing the values of the ADCMPDR0 and ADCMPDR1
registers with results of A/D conversion.
The ADCMPLR1 register should be set while ADCSR.ADST bit is 0.
CMPLCHA1n Bit (n = 00 to 04, 11) (Compare Window A Comparison Condition Select)
This bit sets the condition for use in comparison with the selected channel from among AN016 to AN020 and AN027 to
which compare window A conditions are applied. A condition can be set for individual comparison of each analog input.
The CMPLCHA100 bit is used for AN016 and the CMPLCHA111 bit is used for AN027.
When the result of comparison matches the set condition, the ADCMPSR1.CMPSTCHA1n flag is set to 1.
Figure 44.3 shows the comparison conditions.
Address(es): S12AD.ADCMPLR1 0008 909Ah
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
————
CMPLC
HA111
——————
CMPLC
HA104
CMPLC
HA103
CMPLC
HA102
CMPLC
HA101
CMPLC
HA100
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 CMPLCHA100 Compare Window A
Comparison Condition Select
When the window function is disabled
(ADCMPCR.WCMPE bit = 0):
0: ADCMPDR0 register value > A/D-converted value
1: ADCMPDR0 register value < A/D-converted value
When the window function is enabled
(ADCMPCR.WCMPE bit = 1):
0: A/D-converted value < ADCMPDR0 register value or
A/D-converted value > ADCMPDR1 register value
1: ADCMPDR0 register value < A/D-converted value <
ADCMPDR1 register value
R/W
b1 CMPLCHA101 R/W
b2 CMPLCHA102 R/W
b3 CMPLCHA103 R/W
b4 CMPLCHA104 R/W
b10 to b5 — Reserved These bits are read as 0. The write value should be 0. R/W
b11 CMPLCHA111 Compare Window A
Comparison Condition Select
When the window function is disabled
(ADCMPCR.WCMPE bit = 0):
0: ADCMPDR0 register value > A/D-converted value
1: ADCMPDR0 register value < A/D-converted value
When the window function is enabled
(ADCMPCR.WCMPE bit = 1):
0: A/D-converted value < ADCMPDR0 register value or
A/D-converted value > ADCMPDR1 register value
1: ADCMPDR0 register value < A/D-converted value <
ADCMPDR1 register value
R/W
b15 to b12 — Reserved These bits are read as 0. The write value should be 0. R/W
