R01UH0823EJ0100 Rev.1.00 Page 909 of 1823

Jul 31, 2019

RX23W Group 32. USB 2.0 Host/Function Module (USBc)

32.2.34 USB Module Control Register (USBMC)

VDDUSBE Bit (USB Reference Power Supply Circuit On/Off Control)

The USB reference power supply circuit generates the reference voltage for battery charging. Set this bit to 1 when using

the battery charging function.

Address(es): 000A 00CCh

b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0

———————————————

VDDUS

Value after reset:

0000000000000010

Bit Symbol Bit Name Description R/W

b0 VDDUSBE USB Reference Power Supply

Circuit On/Off Control

0: USB reference power supply circuit off

1: USB reference power supply circuit on

R/W

b1 — Reserved This bit is read as 1. The write value should be 1. R/W

b15 to b2 — Reserved These bits are read as 0. The write value should be 0. R/W
