RX23W Group 36. CAN Module (RSCAN)
36.2.51 Transmit/Receive FIFO Access Register 0BL (CFTS0)
This register can be read when the GRWCR.RPAGE bit is 1.
CFTS[15:0] Bits (Transmit/Receive FIFO Buffer Timestamp Data)
These bits indicate the timestamp value of the message stored in the transmit/receive FIFO buffer.
These bits are valid when the CFCCH0.CFM[1:0] value is 00b.
Address(es): RSCAN0.CFTS0 000A 85E4h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CFTS[15:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b15 to b0 CFTS[15:0] Transmit/Receive FIFO Buffer
Timestamp Data
These bits are valid only when the CFCCH0.CFM[1:0] value
is 00b (receive mode).
The timestamp value of the received message can be read.
R
