R01UH0823EJ0100 Rev.1.00 Page 184 of 1823
Jul 31, 2019
RX23W Group 9. Clock Generation Circuit
9.2.12 High-Speed On-Chip Oscillator Control Register 2 (HOCOCR2)
Note: Set the PRCR.PRC0 bit to 1 (write enabled) before rewriting this register.
High-speed on-chip control register 2 is used to set operation of the high-speed on-chip oscillator.
When the HOCOCR.HCSTP bit is 0 (HOCO is operating), do not write to the HOCOCR2 register.
HCFRQ[1:0] Bits (HOCO Frequency Setting)
These bits set the frequency of the HOCO.
Address(es): 0008 0037h
b7 b6 b5 b4 b3 b2 b1 b0
——————HCFRQ[1:0]
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b1, b0 HCFRQ[1:0] HOCO Frequency Setting
b1 b0
0 0: 32 MHz
1 1: 54 MHz
Settings other than above are prohibited.
R/W
b7 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
