9.2.8 Sub-Clock Oscillator Control Register (SOSCCR)
Note: Set the PRCR.PRC0 bit to 1 (write enabled) before rewriting this register.
SOSTP Bit (Sub-Clock Oscillator Stop)
This bit runs or stops the sub-clock oscillator.
The SOSTP bit and the sub-clock oscillator control bit in RTC control register 3 (RCR3.RTCEN) controls whether to
operate or stop the sub-clock oscillator. If one of these bits is set so as to enable the operation, the sub-clock oscillator
runs.
When changing the value of the SOSTP bit or RCR3.RTCEN bit, execute subsequent instructions after reading the bit
and checking that its value has actually been updated (refer to (2), Notes on writing to I/O registers, in
section 5, I/O
Registers
).
After the setting of the SOSTP bit or the RCR3.RTCEN bit has been changed so that the sub-clock oscillator operates,
only start using the sub-clock after the sub-clock oscillation stabilization time (t
SUBOSC
) has elapsed.
That is, a fixed time for stabilization is required after the setting for sub-clock oscillator operation. A fixed time is also
required for oscillation to stop after the setting to stop the oscillator. Accordingly, take note of the following limitations
when starting and stopping the oscillator.
ï‚· When restarting the sub-clock oscillator after it has been stopped, allow at least five cycles of the sub-clock as an
interval over which it is still stopped.
ï‚· Ensure that oscillation by the sub-clock oscillator is stable when making the setting to stop the sub-clock oscillator.
ï‚· Regardless of whether or not it is selected as the system clock, ensure that oscillation by the sub-clock oscillator is
stable before executing a WAIT instruction to place the chip on software standby.
ï‚· When a transition to software standby mode is to follow the setting to stop the sub-clock oscillator, wait for at least
two cycles of the sub-clock oscillator after the setting to stop the sub-clock oscillator and before executing the
WAIT instruction.
While the sub-clock oscillator is selected by the SCKCR3.CKSEL[2:0] bits, do not set the SOSTP bit to 1 (sub-clock
oscillator is stopped).
Address(es): 0008 0033h
b7 b6 b5 b4 b3 b2 b1 b0
———————SOSTP
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 SOSTP Sub-Clock Oscillator Stop 0: Sub-clock oscillator is operating.
1: Sub-clock oscillator is stopped.
R/W
b7 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
