R01UH0823EJ0100 Rev.1.00 Page 1015 of 1823
Jul 31, 2019
RX23W Group 33. Serial Communications Interface (SCIg, SCIh)
33.2.33 Secondary Control Field 1 Data Register (SCF1DR)
PCF1DR is an 8-bit readable and writable register that holds the 8-bit secondary value for comparison with Control Field
1.
33.2.34 Control Field 1 Compare Enable Register (CF1CR)
33.2.35 Control Field 1 Receive Data Register (CF1RR)
CF1RR is a readable register that holds the value received in Control Field 1.
Address(es): SCI12.SCF1DR 0008 B32Dh
b7 b6 b5 b4 b3 b2 b1 b0
Value after reset:
00000000
Address(es): SCI12.CF1CR 0008 B32Eh
b7 b6 b5 b4 b3 b2 b1 b0
CF1CE
7
CF1CE
6
CF1CE
5
CF1CE
4
CF1CE
3
CF1CE
2
CF1CE
1
CF1CE
0
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 CF1CE0 Control Field 1 Bit 0 Compare Enable 0: Comparison with bit 0 of Control Field 1 is disabled.
1: Comparison with bit 0 of Control Field 1 is enabled.
R/W
b1 CF1CE1 Control Field 1 Bit 1 Compare Enable 0: Comparison with bit 1 of Control Field 1 is disabled.
1: Comparison with bit 1 of Control Field 1 is enabled.
R/W
b2 CF1CE2 Control Field 1 Bit 2 Compare Enable 0: Comparison with bit 2 of Control Field 1 is disabled.
1: Comparison with bit 2 of Control Field 1 is enabled.
R/W
b3 CF1CE3 Control Field 1 Bit 3 Compare Enable 0: Comparison with bit 3 of Control Field 1 is disabled.
1: Comparison with bit 3 of Control Field 1 is enabled.
R/W
b4 CF1CE4 Control Field 1 Bit 4 Compare Enable 0: Comparison with bit 4 of Control Field 1 is disabled.
1: Comparison with bit 4 of Control Field 1 is enabled.
R/W
b5 CF1CE5 Control Field 1 Bit 5 Compare Enable 0: Comparison with bit 5 of Control Field 1 is disabled.
1: Comparison with bit 5 of Control Field 1 is enabled.
R/W
b6 CF1CE6 Control Field 1 Bit 6 Compare Enable 0: Comparison with bit 6 of Control Field 1 is disabled.
1: Comparison with bit 6 of Control Field 1 is enabled.
R/W
b7 CF1CE7 Control Field 1 Bit 7 Compare Enable 0: Comparison with bit 7 of Control Field 1 is disabled.
1: Comparison with bit 7 of Control Field 1 is enabled.
R/W
Address(es): SCI12.CF1RR 0008 B32Fh
b7 b6 b5 b4 b3 b2 b1 b0
Value after reset:
00000000
