R01UH0823EJ0100 Rev.1.00 Page 883 of 1823
Jul 31, 2019
RX23W Group 32. USB 2.0 Host/Function Module (USBc)
32.2.17 BEMP Interrupt Status Register (BEMPSTS)
Note 1. To clear the status indicated by the flags in the BEMPSTS register, write 0 only to the flags to be cleared; write 1 to the other
flags.
Address(es): 000A 004Ah
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
——————
PIPE9B
EMP
PIPE8B
EMP
PIPE7B
EMP
PIPE6B
EMP
PIPE5B
EMP
PIPE4B
EMP
PIPE3B
EMP
PIPE2B
EMP
PIPE1B
EMP
PIPE0B
EMP
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 PIPE0BEMP BEMP Interrupt Status Flag for PIPE0 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b1 PIPE1BEMP BEMP Interrupt Status Flag for PIPE1 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b2 PIPE2BEMP BEMP Interrupt Status Flag for PIPE2 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b3 PIPE3BEMP BEMP Interrupt Status Flag for PIPE3 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b4 PIPE4BEMP BEMP Interrupt Status Flag for PIPE4 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b5 PIPE5BEMP BEMP Interrupt Status Flag for PIPE5 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b6 PIPE6BEMP BEMP Interrupt Status Flag for PIPE6 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b7 PIPE7BEMP BEMP Interrupt Status Flag for PIPE7 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b8 PIPE8BEMP BEMP Interrupt Status Flag for PIPE8 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b9 PIPE9BEMP BEMP Interrupt Status Flag for PIPE9 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b15 to b10 — Reserved These bits are read as 0. The write value should be 0. R/W
