R01UH0823EJ0100 Rev.1.00 Page 1813 of 1823
Jul 31, 2019
RX23W Group 51. Electrical Characteristics
51.15 BLE Characteristics
51.15.1 Transmission Characteristics
Note: The characteristics are based on pins and functions other than those for the BLE interface not being in use.
Note 1. This does not take frequency errors due to manufacturing irregularities, drift with temperature, or deterioration of the crystal over
time into account.
51.15.2 Reception Characteristics (2 Mbps)
Note: The characteristics are based on pins and functions other than those for the BLE interface not being in use.
Note 1. PER ≤ 30.8%, and a 37-byte payload
Note 2. Allowable range of difference between the center frequency for the RF input signals and the carrier frequency generated within
the chip
Table 51.61 Transmission Characteristics
Conditions: VCC = VCC_RF = AVCC_RF = 3.3 V, VSS = VSS_RF = 0 V, T
a
= +25°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Range of frequency RF
CF
2402 — 2480 MHz
Data rate RF
DATA_2M
—2—Mbps
RF
DATA_1M
—1—Mbps
RF
DATA_500k
— 500 — kbps
RF
DATA_125k
— 125 — kbps
Maximum transmitted output
power
RF
POWER
— 0 2 dBm 0 dBm output mode
— 4 6 dBm 4 dBm output mode
Output frequency error RF
TXFERR
–10 — 10 ppm *
1
Table 51.62 Reception Characteristics
Conditions: VCC = VCC_RF = AVCC_RF = 3.3 V, VSS = VSS_RF = 0 V, T
a
= +25°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Input frequency RF
RXFIN_2M
2402 — 2480 MHz
Maximum input level RF
LEVL_2M
–10 4 — dBm *
1
Receiver sensitivity RF
STY_2M
— –92 — dBm *
1
Secondary emission strength RF
RXSP_2M
— –72 –57 dBm 30 MHz to 1 GHz
— –54 –47 dBm 1 GHz to 12 GHz
Co-channel rejection ratio RF
CCR_2M
— –8 — dB Prf = –67 dBm*
1
Adjacent channel rejection
ratio
RF
ADCR_2M
— 2 — dB Prf = –67 dBm*
1
±2 MHz
—35—dB ±4 MHz
—39—dB ±6 MHz
Blocking RF
BLK_2M
— –1 — dBm Prf = –67 dBm*
1
30 MHz to 2000 MHz
— –25 — dBm 2000 MHz to 2399 MHz
— –21 — dBm 2484 MHz to 3000 MHz
— –10 — dBm > 3000 MHz
Allowable frequency
deviation*
2
RF
RXFER_2M
–120 — 120 ppm *
1
RSSI accuracy RF
RSSIS_2M
— ±4 — dB –70 dBm ≤ Prf ≤ –10 dBm
