RX23W Group 48. Data Operation Circuit (DOC)
48.2 Register Descriptions
48.2.1 DOC Control Register (DOCR)
Note 1. Valid only when data comparison mode is selected.
OMS[1:0] Bits (Operating Mode Select)
These bits select the operating mode of the data operation circuit.
DCSEL Bit (Detection Condition Select)
This bit is valid only when data comparison mode is selected.
This bit selects the condition for detection in data comparison mode.
DOPCIE Bit (Data Operation Circuit Interrupt Enable)
Setting this bit to 1 enables interrupts from the data operation circuit.
DOPCF Flag (Data Operation Circuit Flag)
[Setting conditions]
The condition selected by the DCSEL bit is met
A result of data addition is greater than FFFFh
A result of data subtraction is less than 0000h
[Clearing condition]
Writing 1 to the DOPCFCL bit
DOPCFCL Bit (DOPCF Clear)
Setting this bit to 1 clears the DOPCF flag.
This bit is read as 0.
Address(es): 0008 B080h
b7 b6 b5 b4 b3 b2 b1 b0
—
DOPCF
CL
DOPCF
DOPCI
E
— DCSEL OMS[1:0]
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b1, b0 OMS[1:0] Operating Mode Select
b1 b0
0 0: Data comparison mode
0 1: Data addition mode
1 0: Data subtraction mode
1 1: Setting prohibited
R/W
b2 DCSEL
*1
Detection Condition Select Result of data comparison
0: Data mismatch is detected.
1: Data match is detected.
R/W
b3 — Reserved This bit is read as 0. The write value should be 0. R/W
b4 DOPCIE Data Operation Circuit
Interrupt Enable
0: Disables interrupts from the data operation circuit.
1: Enables interrupts from the data operation circuit.
R/W
b5 DOPCF Data Operation Circuit Flag Indicates the result of an operation. R
b6 DOPCFCL DOPCF Clear 0: Maintains the DOPCF flag state.
1: Clears the DOPCF flag.
R/W
b7 — Reserved This bit is read as 0. The write value should be 0. R/W
