RX23W Group 18. DMA Controller (DMACA)
18.2.4 DMA Block Transfer Count Register (DMCRB)
DMCRB specifies the number of block transfer operations and repeat transfer operations in block and repeat transfer
mode, respectively.
The number of transfer operations is one when the setting is 001h, 1023 when it is 3FFh, and 1024 when it is 000h.
In repeat transfer mode, the value is decremented by one when the final data of one repeat size is transferred.
In block transfer mode, the value is decremented by one when the final data of one block size is transferred.
In normal transfer mode, DMCRB is not used. The setting is invalid.
Address(es): DMAC0.DMCRB 0008 200Ch, DMAC1.DMCRB 0008 204Ch, DMAC2.DMCRB 0008 208Ch, DMAC3.DMCRB 0008 20CCh
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
——————
Value after reset:
0000000000000000
Bit Description Setting Range R/W
b9 to b0 Specifies the number of block transfer operations
or repeat transfer operations.
001h to 3FFh (1 to 1023)
000h (1024)
R/W
b15 to b10 Reserved These bits are read as 0. The write value should be 0. R/W
