Renesas RX Series - Voltage Monitoring Circuit Control Register (LVCMPCR)

To Next Page

To Previous Page

R01UH0823EJ0100 Rev.1.00 Page 160 of 1823

Jul 31, 2019

RX23W Group 8. Voltage Detection Circuit (LVDAb)

8.2.3 Voltage Monitoring Circuit Control Register (LVCMPCR)

Note: Set the PRCR.PRC3 bit to 1 (write enabled) before rewriting this register.

LVD1E Bit (Voltage Detection 1 Enable)

When using voltage detection 1 interrupt/reset or the LVD1SR.LVD1MON flag, set the LVD1E bit to 1. The voltage

detection 1 circuit starts once td(E-A) passes after the LVD1E bit value is changed from 0 to 1.

Address(es): 0008 C297h

b7 b6 b5 b4 b3 b2 b1 b0

——LVD1E—————

Value after reset:

00000000

Bit Symbol Bit Name Description R/W

b4 to b0

—

Reserved These bits are read as 0. The write value should be 0. R/W

b5 LVD1E Voltage Detection 1 Enable 0: Voltage detection 1 circuit disabled

1: Voltage detection 1 circuit enabled

R/W

b7, b6

—

Reserved These bits are read as 0. The write value should be 0. R/W
