R01UH0823EJ0100 Rev.1.00 Page 1248 of 1823
Jul 31, 2019
RX23W Group 36. CAN Module (RSCAN)
36.2.64 Transmit Buffer Transmit Complete Status Register (TMTCSTS)
TMTCSTSp Flag (RSCAN0 Transmit Buffer p Transmit Complete Status Flag) (p = 0 to 3)
When the TMSTSp.TMTRF[1:0] flags become 10b (transmission has been completed (without transmit abort request))
or 11b (transmission has been completed (with transmit abort request)), the corresponding TMTCSTSp flag becomes 1.
This flag becomes 0 when the corresponding TMSTSp.TMTRF[1:0] flags are set to 00b or in channel reset mode.
Address(es): RSCAN0.TMTCSTS 000A 8376h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
————————————
TMTCS
TS3
TMTCS
TS2
TMTCS
TS1
TMTCS
TS0
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 TMTCSTS0 RSCAN0 Transmit Buffer 0
Transmit Complete Status Flag
0: Transmission has not been completed.
1: Transmission has been completed.
R
b1 TMTCSTS1 RSCAN0 Transmit Buffer 1
Transmit Complete Status Flag
R
b2 TMTCSTS2 RSCAN0 Transmit Buffer 2
Transmit Complete Status Flag
R
b3 TMTCSTS3 RSCAN0 Transmit Buffer 3
Transmit Complete Status Flag
R
b15 to b4 — Reserved These bits are read as 0. R
