R01UH0823EJ0100 Rev.1.00 Page 1411 of 1823
Jul 31, 2019
RX23W Group 38. Serial Peripheral Interface (RSPIa)
38.4.4 RSPI Idle Event Output
(1) In Master Mode
In master mode, an event is output when the condition for setting the IDLNF flag (RSPI idle flag) to 0 is satisfied.
(2) In Slave Mode
In slave mode, an event is output when the SPCR.SPE bit is set to 0 (RSPI is initialized).
38.4.5 Transmission-Completed Event Output
During both SPI operation and clock synchronous operation in master mode, an event is output under the condition for
setting the IDLNF flag (RSPI idle flag) from 1 to 0.
Whether the operation is in master mode or slave mode, an event is not output if 0 is written to the SPCR.SPE bit in
transmission or the SPCR.SPE bit is cleared by the mode fault error.
Table 38.15 Conditions for Generation of a Transmission-Completed Event (Slave)
Transmit Buffer State Shift Register State Others
SPI operation (SPMS = 0) Empty Empty Negation of SSLA0 input
Clock synchronous operation
(SPMS = 1)
Empty Empty Edge detection of the last RSPCKA
