RX23W Group 6. Resets
6. Resets
6.1 Overview
The following resets are implemented: RES# pin reset, power-on reset, voltage monitoring 0 reset, voltage monitoring 1
reset, independent watchdog timer reset, watchdog timer reset, and software reset.
Table 6.1 lists the reset names and sources.
Note 1. For the voltages to be monitored (VPOR, Vdet0, and Vdet1), see section 8, Voltage Detection Circuit (LVDAb) and section 51,
Electrical Characteristics.
Table 6.1 Reset Names and Sources
Reset Name Source
RES# pin reset Voltage input to the RES# pin is driven low.
Power-on reset VCC rises (voltage monitored: VPOR)
*1
Voltage monitoring 0 reset VCC falls (voltage monitored: Vdet0)
*1
Voltage monitoring 1 reset VCC falls (voltage monitored: Vdet1)
*1
Independent watchdog timer reset The independent watchdog timer underflows, or a refresh error occurs.
Watchdog timer reset The watchdog timer underflows, or a refresh error occurs.
Software reset Register setting
