Renesas RX Series

R01UH0823EJ0100 Rev.1.00 Page 1638 of 1823
Jul 31, 2019
RX23W Group 47. Comparator B (CMPBa)
47.2 Register Descriptions
47.2.1 Comparator B1 Control Register 1 (CPB1CNT1)
47.2.2 Comparator B1 Control Register 2 (CPB1CNT2)
Address: 0008 C5A0h
b7 b6 b5 b4 b3 b2 b1 b0
———
CPB3I
NI
———
CPB2I
NI
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 CPB2INI Comparator B2 Power Enable 0: Disabled
1: Enabled (comparator powered on)
R/W
b3 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
b4 CPB3INI Comparator B3 Power Enable 0: Disabled
1: Enabled (comparator powered on)
R/W
b7 to b5 — Reserved These bits are read as 0. The write value should be 0. R/W
Address: 0008 C5A1h
b7 b6 b5 b4 b3 b2 b1 b0
———
CPB3W
CP
———
CPB2W
CP
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 CPB2WCP Comparator B2 Window Function Enable 0: Disabled
1: Enabled
R/W
b3 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
b4 CPB3WCP Comparator B3 Window Function Enable 0: Disabled
1: Enabled
R/W
b7 to b5 — Reserved These bits are read as 0. The write value should be 0. R/W
