RX23W Group 38. Serial Peripheral Interface (RSPIa)
38.2.2 RSPI Slave Select Polarity Register (SSLP)
Do not change the SSLP register while the SPCR.SPE bit is 1.
Address(es): RSPI0.SSLP 0008 8381h
b7 b6 b5 b4 b3 b2 b1 b0
————SSL3P—SSL1PSSL0P
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 SSL0P SSL0 Signal Polarity Setting 0: SSL0 signal is active low
1: SSL0 signal is active high
R/W
b1 SSL1P SSL1 Signal Polarity Setting 0: SSL1 signal is active low
1: SSL1 signal is active high
R/W
b2 — Reserved This bit is read as 0. The write value should be 0. R/W
b3 SSL3P SSL3 Signal Polarity Setting 0: SSL3 signal is active low
1: SSL3 signal is active high
R/W
b7 to b4 — Reserved These bits are read as 0. The write value should be 0. R/W
