R01UH0823EJ0100 Rev.1.00 Page 1011 of 1823
Jul 31, 2019
RX23W Group 33. Serial Communications Interface (SCIg, SCIh)
33.2.26 Interrupt Control Register (ICR)
Address(es): SCI12.ICR 0008 B326h
b7 b6 b5 b4 b3 b2 b1 b0
— — AEDIE BCDIE PIBDIE
CF1MI
E
CF0MI
E
BFDIE
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 BFDIE Break Field Low Width Detected
Interrupt Enable
0: Interrupts on detection of the low width for a Break Field
are disabled.
1: Interrupts on detection of the low width for a Break Field
are enabled.
R/W
b1 CF0MIE Control Field 0 Match Detected
Interrupt Enable
0: Interrupts on detection of a match with Control Field 0 are
disabled.
1: Interrupts on detection of a match with Control Field 0 are
enabled.
R/W
b2 CF1MIE Control Field 1 Match Detected
Interrupt Enable
0: Interrupts on detection of a match with Control Field 1 are
disabled.
1: Interrupts on detection of a match with Control Field 1 are
enabled.
R/W
b3 PIBDIE Priority Interrupt Bit Detected Interrupt
Enable
0: Interrupts on detection of the priority interrupt bit are
disabled.
1: Interrupts on detection of the priority interrupt bit are
enabled.
R/W
b4 BCDIE Bus Collision Detected Interrupt Enable 0: Interrupts on detection of a bus collision are disabled.
1: Interrupts on detection of a bus collision are enabled.
R/W
b5 AEDIE Valid Edge Detected Interrupt Enable 0: Interrupts on detection of a valid edge are disabled.
1: Interrupts on detection of a valid edge are enabled.
R/W
b7, b6 — Reserved These bits are read as 0. The write value should be 0. R/W
