RX23W Group 5. I/O Registers
0008 C416h RTC Binary Counter 3 Alarm Register BCNT3AR 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C418h RTC Date Alarm Register RDAYAR 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C418h RTC Binary Counter 0 Alarm Enable Register BCNT0AER 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C41Ah RTC Month Alarm Register RMONAR 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C41Ah RTC Binary Counter 1 Alarm Enable Register BCNT1AER 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C41Ch RTC Year Alarm Register RYRAR 16 16 2 or 3 PCLKB 2 ICLK section 28.
0008 C41Ch RTC Binary Counter 2 Alarm Enable Register BCNT2AER 16 16 2 or 3 PCLKB 2 ICLK section 28.
0008 C41Eh RTC Year Alarm Enable Register RYRAREN 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C41Eh RTC Binary Counter 3 Alarm Enable Register BCNT3AER 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C422h RTC RTC Control Register 1 RCR1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C424h RTC RTC Control Register 2 RCR2 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C426h RTC RTC Control Register 3 RCR3 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C42Eh RTC Time Error Adjustment Register RADJ 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C440h RTC Time Capture Control Register 0 RTCCR0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C442h RTC Time Capture Control Register 1 RTCCR1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C452h RTC Second Capture Register 0 RSECCP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C452h RTC BCNT0 Capture Register 0 BCNT0CP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C454h RTC Minute Capture Register 0 RMINCP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C454h RTC BCNT1 Capture Register 0 BCNT1CP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C456h RTC Hour Capture Register 0 RHRCP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C456h RTC BCNT2 Capture Register 0 BCNT2CP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C45Ah RTC Date Capture Register 0 RDAYCP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C45Ah RTC BCNT3 Capture Register 0 BCNT3CP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C45Ch RTC Month Capture Register 0 RMONCP0 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C462h RTC Second Capture Register 1 RSECCP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C462h RTC BCNT0 Capture Register 1 BCNT0CP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C464h RTC Minute Capture Register 1 RMINCP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C464h RTC BCNT1 Capture Register 1 BCNT1CP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C466h RTC Hour Capture Register 1 RHRCP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C466h RTC BCNT2 Capture Register 1 BCNT2CP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C46Ah RTC Date Capture Register 1 RDAYCP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C46Ah RTC BCNT3 Capture Register 1 BCNT3CP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C46Ch RTC Month Capture Register 1 RMONCP1 8 8 2 or 3 PCLKB 2 ICLK section 28.
0008 C5A0h CMPB Comparator B1 Control Register 1 CPB1CNT1 8 8 2 or 3 PCLKB 2 ICLK section 47.
0008 C5A1h CMPB Comparator B1 Control Register 2 CPB1CNT2 8 8 2 or 3 PCLKB 2 ICLK section 47.
0008 C5A2h CMPB Comparator B1 Flag Register CPB1FLG 8 8 2 or 3 PCLKB 2 ICLK section 47.
0008 C5A3h CMPB Comparator B1 Interrupt Control Register CPB1INT 8 8 2 or 3 PCLKB 2 ICLK section 47.
0008 C5A4h CMPB Comparator B1 Filter Select Register CPB1F 8 8 2 or 3 PCLKB 2 ICLK section 47.
0008 C5A5h CMPB Comparator B1 Mode Select Register CPB1MD 8 8 2 or 3 PCLKB 2 ICLK section 47.
0008 C5A6h CMPB Comparator B1 Reference Input Voltage Select Register CPB1REF 8 8 2 or 3 PCLKB 2 ICLK section 47.
0008 C5A7h CMPB Comparator B1 Output Control Register CPB1OCR 8 8 2 or 3 PCLKB 2 ICLK section 47.
000A 0000h USB0 System Configuration Control Register SYSCFG 16 16 3, 4 PCLKB 2 ICLK section 32.
000A 0004h USB0 System Configuration Status Register 0 SYSSTS0 16 16 9 PCLKB
or more
Rounded up to
the nearest
integer greater
than 1 + 9 ×
(frequency
ratio of ICLK/
PCLKB)*
2
section 32.
000A 0008h USB0 Device State Control Register 0 DVSTCTR0 16 16 9 PCLKB
or more
Rounded up to
the nearest
integer greater
than 1 + 9 ×
(frequency
ratio of ICLK/
PCLKB)*
2
section 32.
000A 0014h USB0 CFIFO Port Register CFIFO 16 16 3, 4 PCLKB 2 ICLK section 32.
Table 5.1 List of I/O Registers (Address Order) (17/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
