Renesas RX Series

R01UH0823EJ0100 Rev.1.00 Page 125 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
000A 00D2h USB0 Device Address 1 Configuration Register DEVADD1 16 169 PCLKB
or more
Frequency
with 1 + 9 ×
(frequency
ratio of ICLK/
PCLKB)*
2
section 32.
000A 00D4h USB0 Device Address 2 Configuration Register DEVADD2 16 169 PCLKB
or more
Frequency
with 1 + 9 ×
(frequency
ratio of ICLK/
PCLKB)*
2
section 32.
000A 00D6h USB0 Device Address 3 Configuration Register DEVADD3 16 169 PCLKB
or more
Frequency
with 1 + 9 ×
(frequency
ratio of ICLK/
PCLKB)*
2
section 32.
000A 00D8h USB0 Device Address 4 Configuration Register DEVADD4 16 169 PCLKB
or more
Frequency
with 1 + 9 ×
(frequency
ratio of ICLK/
PCLKB)*
2
section 32.
000A 00DAh USB0 Device Address 5 Configuration Register DEVADD5 16 169 PCLKB
or more
Frequency
with 1 + 9 ×
(frequency
ratio of ICLK/
PCLKB)*
2
section 32.
000A 0900h CTSU CTSU Control Register 0 CTSUCR0 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0901h CTSU CTSU Control Register 1 CTSUCR1 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0902h CTSU CTSU Synchronous Noise Reduction Setting Register CTSUSDPRS 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0903h CTSU CTSU Sensor Stabilization Wait Control Register CTSUSST 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0904h CTSU CTSU Measurement Channel Register 0 CTSUMCH0 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0905h CTSU CTSU Measurement Channel Register 1 CTSUMCH1 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0906h CTSU CTSU Channel Enable Control Register 0 CTSUCHAC0 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0907h CTSU CTSU Channel Enable Control Register 1 CTSUCHAC1 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0908h CTSU CTSU Channel Enable Control Register 2 CTSUCHAC2 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0909h CTSU CTSU Channel Enable Control Register 3 CTSUCHAC3 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 090Ah CTSU CTSU Channel Enable Control Register 4 CTSUCHAC4 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 090Bh CTSU CTSU Channel Transmit/Receive Control Register 0 CTSUCHTRC0 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 090Ch CTSU CTSU Channel Transmit/Receive Control Register 1 CTSUCHTRC1 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 090Dh CTSU CTSU Channel Transmit/Receive Control Register 2 CTSUCHTRC2 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 090Eh CTSU CTSU Channel Transmit/Receive Control Register 3 CTSUCHTRC3 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 090Fh CTSU CTSU Channel Transmit/Receive Control Register 4 CTSUCHTRC4 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0910h CTSU CTSU High-Pass Noise Reduction Control Register CTSUDCLKC 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0911h CTSU CTSU Status Register CTSUST 8 8 2 or 3 PCLKB 2 ICLK section 43.
000A 0912h CTSU CTSU High-Pass Noise Reduction Spectrum Diffusion
Control Register
CTSUSSC 16 16 2 or 3 PCLKB 2 ICLK section 43.
000A 0914h CTSU CTSU Sensor Offset Register 0 CTSUSO0 16 16 2 or 3 PCLKB 2 ICLK section 43.
000A 0916h CTSU CTSU Sensor Offset Register 1 CTSUSO1 16 16 2 or 3 PCLKB 2 ICLK section 43.
000A 0918h CTSU CTSU Sensor Counter CTSUSC 16 16 2 or 3 PCLKB 2 ICLK section 43.
000A 091Ah CTSU CTSU Reference Counter CTSURC 16 16 2 or 3 PCLKB 2 ICLK section 43.
000A 091Ch CTSU CTSU Error Status Register CTSUERRS 16 16 2 or 3 PCLKB 2 ICLK section 43.
000A 8300h RSCAN0 Bit Configuration Register L CFGL 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8302h RSCAN0 Bit Configuration Register H CFGH 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8304h RSCAN0 Control Register L CTRL 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8306h RSCAN0 Control Register H CTRH 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8308h RSCAN0 Status Register L STSL 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 830Ah RSCAN0 Status Register H STSH 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 830Ch RSCAN0 Error Flag Register L ERFLL 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 830Eh RSCAN0 Error Flag Register H ERFLH 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8322h RSCAN Global Configuration Register L GCFGL 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8324h RSCAN Global Configuration Register H GCFGH 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8326h RSCAN Global Control Register L GCTRL 16 16 2 or 3 PCLKB 2 ICLK section 36.
Table 5.1 List of I/O Registers (Address Order) (21/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
