Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 1531 of 1823
Jul 31, 2019
RX23W Group 44. 12-Bit A/D Converter (S12ADE)
Table 44.1 Specifications of 12-Bit A/D Converter (1/2)
Item Description
Number of units One unit
Input channels Up to 14 channels
Extended analog function Temperature sensor output, internal reference voltage
A/D conversion method Successive approximation method
Resolution 12 bits
Conversion time 0.83 μs per channel
(when A/D conversion clock ADCLK = 54 MHz)
A/D conversion clock Peripheral module clock PCLK*
1
and A/D conversion clock ADCLK*
1
can be set so that the frequency ratio
should be one of the following.
PCLK to ADCLK frequency ratio = 1:1, 1:2, 2:1, 4:1, 8:1
ADCLK is set using the clock generation circuit.
Data registers
 14 registers for analog input, 1 for A/D-converted data duplication in double trigger mode
 One register for temperature sensor output
 One register for internal reference voltage
 One register for self-diagnosis
 The results of A/D conversion are stored in 12-bit A/D data registers.
 12-bit accuracy output for the results of A/D conversion
 The value obtained by adding up A/D-converted results is stored as a value in the number of bit for
conversion accuracy + 2 bits/4 bits*
2
in the A/D data registers in A/D-converted value addition mode.
 Double trigger mode (selectable in single scan and group scan modes):
The first piece of A/D-converted analog-input data on one selected channel is stored in the data register
for the channel, and the second piece is stored in the duplication register.
Operating modes
 Single scan mode:
A/D conversion is performed only once on the analog inputs of up to 14 channels arbitrarily selected.
A/D conversion is performed only once on the temperature sensor output.
A/D conversion is performed only once on the internal reference voltage.
 Continuous scan mode:
A/D conversion is performed repeatedly on the analog inputs of up to 14 channels arbitrarily selected.
 Group scan mode:
Analog inputs of up to 14 channels arbitrarily selected, are divided into group A and group B, and A/D
conversion of the analog input selected on a group basis is performed only once.
The conditions for scanning start of group A and group B (synchronous trigger) can be independently
selected, thus allowing A/D conversion of group A and group B to be started independently.
 Group scan mode (when group A is given priority):
If a group A trigger is input during A/D conversion on group B, the A/D conversion on group B is stopped
and A/D conversion is performed on group A.
Restart (rescan) of A/D conversion on group B after completion of A/D conversion on group A can be set.
Conditions for A/D
conversion start
 Software trigger
 Synchronous trigger
Trigger by the multi-function timer pulse unit (MTU), the event link controller (ELC), or the 16-bit timer
pulse unit (TPU).
 Asynchronous trigger
A/D conversion can be triggered by the external trigger ADTRG0# pin.
Functions
 Variable sampling state count
 Self-diagnosis of 12-bit A/D converter
 Selectable A/D-converted value addition mode or average mode
 Analog input disconnection detection function (discharge function/precharge function)
 Double trigger mode (duplication of A/D conversion data)
 Automatic clear function of A/D data registers
 Compare function (window A and window B)
 16 ring buffers when the compare function is used
