January 2007
4-187
WorkCentre 7132
REP 16.12.2
Repairs/Adjustments
Reversion 4.0
Figure 3 Removing the Stacker Bracket
3. Disconnect the Connector. (Figure 4)
Figure 4 Disconnecting the connector
4. Remove the Right Cover. (Figure 5)
1. Remove the Right Cover.
1
Disconnect the Con-
nector
