Xerox WorkCentre 7132

January 2007
4-252
WorkCentre 7132
ADJ 9.1.10
Reversion 4.0
Repairs/Adjustments
8. Run Pro Con “Off” and compare the two prints.
Corrective Action 1
Corrective Action
1. Procon Area
• ADC (Automatic Density Control) Target vs. Measured more than 30 bits off.
2. Prints And What To Look At.
• internal test pattern 53, Low, mid and high patches.
3. Corrective Action
• If the problem is in high density patches, then troubleshoot IOT problems.
• If the problem is only in low and mid density patches then perform TRC Adjustment
and adjust low, mid and high starting with low density.
NOTE: Center value is “0”. Range is -128 to 127
Corrective Action 2
Corrective Action
1. Procon Area
• ADC (Automatic Density Control) Shutter Open Fail (NG) or ADC Shutter Close Fail
(NG).
2. Prints And What To Look At.
• (Nothing to look at)
3. Corrective Action
• Check the connections to the ADC Sensor.
• Check the operation and condition of the Shutter.
• If OK, replace the ADC/MOB/Temp/Humidity sensor bar. (PL 11.1)
Table 2 PRO CON “Off”
PRO CON On Print Yellow Magenta Cyan Black (K) Remarks
Target ADC - H 385 340 400 165
ADC Measurement - H 381 344 403 167
ADC LS 1 Measurement - H 474 418 500 212
ADC LS 2 Measurement - H 376 259 336 132
Target ADC - M 680 605 645 475
ADC Measurement - M 669 636 659 509
ADC LS 1 Measurement - M 723 680 726 544
ADC LS 2 Measurement - M 646 552 612 474
Target ADC - L 915 915 915 845
ADC Measurement - L 920 923 932 852
ADC LS 1 Measurement - L 943 948 971 860
ADC LS 2 Measurement - L 914 889 908 836
ADC Patch Fail OK OK OK OK
ADC Sensor Fail OK - - -
ADC Shutter open Fail OK - - -
ADC Shutter close fail OK - - -
ADC Mini setup Fail OK OK OK OK
Grid Voltage setting Common 715 715 715 715
Illumination Settings 433 347 335 423
Maximum Illuminations 674 674 674 674
Bias Settings 570 580 580 562
Target TC 432 423 417 282
TC Measurement TC Patch Fail 411 365 366 260
Temperature 26 - - -
Humidity 51 - - -
Temperature Fail OK - - -
Humidity Fail OK - - -
