Xerox WorkCentre 7132

January 2007
6-61
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
747-406 System Register Max Value R5 (Env5) 100 0~10000 System Register Max Value R5 (Env5)
747-407 System Register Max Value R6 (Env6) 100 0~10000 System Register Max Value R6 (Env6)
747-408 System Register Max Value R7 (Env7) 150 0~10000 System Register Max Value R7 (Env7)
747-409 System Register Max Value R8 (Env8) 300 0~10000 System Register Max Value R8 (Env8)
747-410 System Register Max Value R9 (Env9) 600 0~10000 System Register Max Value R9 (Env9)
747-411 Counter is Over System Register Max Value 0 0~65535 Counter is Over System Register Max Value
747-905 Chosen 2nd BTR reference output storage(Side1) 0 0~600 Chosen 2nd BTR reference output storage(Side1)
747-906 Chosen 2nd BTR reference output storage(Side2) 0 0~600 Chosen 2nd BTR reference output storage(Side2)
747-907 2nd BTR Contact Timing (full speed) 1049 0~2000 2nd BTR Contact Timing (full speed)
747-908 2nd BTR Contact Timing (halfspeed) 1694 0~2000 2nd BTR Contact Timing (halfspeed)
747-909 2nd BTR Retract Timing (full speed) 645 0~1000 2nd BTR Retract Timing (full speed)
747-910 2nd BTR Retract Timing (half speed) 1295 0~2000 2nd BTR Retract Timing (half speed)
747-911 2nd BTR Contact movement stop Timing 874 0~1500 2nd BTR Contact movement stop Timing
747-912 2nd BTR Retract movement stop Timing 49 0~1500 2nd BTR Retract movement stop Timing
747-913 2nd BTR Print output On Timing (full speed) 1599 50~2000 2nd BTR Print output On Timing (full speed)
747-914 2nd BTR Print output On Timing (halfspeed) 2013 50~3000 2nd BTR Print output On Timing (halfspeed)
747-915 2nd BTR Print output Off Timing (full speed) 41 0~1000 2nd BTR Print output Off Timing (full speed)
747-916 2nd BTR Print output Off Timing (halfspeed) 81 0~1000 2nd BTR Print output Off Timing (halfspeed)
747-917 2nd BTR Contact Timing in Position_B (full speed) 1049 0~2000 2nd BTR Contact Timing in Position_B (full speed)
747-919 2nd BTR Print output On Timing in Position_B(full speed) 1599 50~2000 2nd BTR Print output On Timing in Position_B(full speed)
747-927 The 2nd BTR Print output Off Timing of Size Mismatch
FullSpeeg Printoutput ->CLN (+)
0 0~2550 The 2nd BTR Print output Off Timing of Size Mismatch
FullSpeeg Printoutput ->CLN (+)
747-928 The 2nd BTR Print output Off Timing of Size Mismatch
HalfSpeed Printoutput ->CLN (+)
0 0~4500 The 2nd BTR Print output Off Timing of Size Mismatch
HalfSpeed Printoutput ->CLN (+)
747-929 IBT CLN Contact Timing (full speed) 2859 2000~4000 IBT CLN Contact Timing (full speed)
747-930 IBT CLN Contact Timing (BW_halfl speed) 3604 3000~5000 IBT CLN Contact Timing (BW_halfl speed)
747-931 IBT CLN Contact Timing (FC_half speed) 3454 3000~5000 IBT CLN Contact Timing (FC_half speed)
747-932 IBT CLN Retract Timing (BW_ full speed) 3095 2000~5000 IBT CLN Retract Timing (BW_ full speed)
747-933 IBT CLN Retract Timing (FC_ full speed) 3095 2000~5000 IBT CLN Retract Timing (FC_ full speed)
747-934 IBT CLN Retract Timing (BW_ halfspeed) 3158 2000~5000 IBT CLN Retract Timing (BW_ halfspeed)
747-935 IBT CLN Retract Timing (FC_ halfspeed) 3032 2000~5000 IBT CLN Retract Timing (FC_ halfspeed)
747-936 IBT CLN Contact movement stop Timing 391 0~800 IBT CLN Contact movement stop Timing
747-937 IBT CLN Retract movement stop Timing 12 0~800 IBT CLN Retract movement stop Timing
747-938 The chosen the second transcription coefficient_SIDE2:
Alpha storage
0 0~6000 The chosen the second transcription coefficient_SIDE2:
Alpha storage
747-939 The chosen the second transcription coefficient_SIDE2:
Beta storage
0 0~6000 The chosen the second transcription coefficient_SIDE2:
Beta storage
747-940 Transcription belt reverse sw 1 0~1 SW that enables rotating Transfer Belt in reverse direction (Job divided)
747-941 Transcription belt reverse pv threshold value 250 1~1000 Transfer Belt Reverse Rotation pv Threshold (Job divided)
747-942 Transcription belt reverse pv counter storage 0 0~1000 Transfer Belt Reverse Rotation pv Counter Storage (Job divided)
Table 6 Xfer
Chain-Link Name Default Range Description
