Xerox WorkCentre 7132

January 2007
6-62
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
Chain 749-xxx ROS
747-943 high document ibt cln cycle
sw
1 0~1 SW that enables IBT CLN cycle for an image with a high resolution
747-944 2nd BTR parameter designated (BW/FC, Common Heavy1 paper _S) 0 0~1 2nd BTR parameter designated (BW/FC, Common Heavy1 paper _S)
0:usually_PARA
1:heavy1S_PARA
747-945 2nd BTR parameter designated (FC,Heavy1 paper _S) 30 0~50 Waiting time from the end of reverse rotation of Transfer Belt to the start of the
next print
747-946 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.0_S1)
747-947 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.1_S1)
747-948 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.2_S1)
747-949 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.3_S1)
747-950 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.4_S1)
747-951 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.5_S1)
747-952 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.6_S1)
747-953 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.7_S1)
747-954 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.8_S1)
747-955 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (BW_Full_Env.9_S1)
747-956 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.0_S1)
747-957 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.1_S1)
747-958 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.2_S1)
747-959 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.3_S1)
747-960 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.4_S1)
747-961 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.5_S1)
747-962 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.6_S1)
747-963 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.7_S1)
747-964 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.8_S1)
747-965 2nd BTR Paper kind compensation coefficient label 100 0~255 2nd BTR Paper kind compensation coefficient label NA (FC_Half_Env.9_S1)
Table 6 Xfer
Chain-Link Name Default Range Description
Table 7 ROS
Chain-Link Name Default Range Description
749-001 Polygon Motor Off Delay Time 1 1~10 Time from the end of exposure of last image to the start of stopping Polygon Motor
[sec]
749-002 Fast Polygon Motor Start Time Out 10 0~30 Time [sec] before Polygon Motor is turned Off in case the machine is not instructed to start printing
though Polygon Motor is activated in advance.
[sec]
749-003 ROS Fan On Temp 24 15~30 Environment temp [degree C] where ROS Fan is rotated during rotation of Polygon Motor
749-004 ROS Fan Stop Delay Time 10 6~14 Time [sec] before ROS Fan is rotated after Polygon Motor stops rotating
749-005 600 0~65535 Delay start of the ROS Shutter close process (msec)
749-006 100 100~4096 Number of input pulse per ROS Shutter close process (pps)
749-007 0 0~65535 Time period of ROS Shutter close process (10msec)
