Xerox WorkCentre 7132

January 2007
6-63
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
Chain 751-xxx 752-xxx Chain 753-xxx Procon
749-008 0 0~1 Rotation direction to close ROS Shutter
0: Clockwise
1: Counter Clockwise
749-009 100 100~4096 Number of input pulse per ROS Shutter open process (pps)
749-010 0 0~65535 Time period of ROS Shutter open process (10msec)
749-011 0 0~1 Rotation direction to open ROS Shutter
0: Clockwise
1: Counter Clockwise
749-012 Video Asic Fail R/W NG Counter 0 0~6 the number of R/W NG results when Video ASIC Fail occurs
749-020 Halftone Pattern1 0 0~65535 Halftone Pattern 1
[16-bit data]
749-021 Halftone Pattern2 0 0~65535 Halftone Pattern 2
[16-bit data]
749-022 Halftone Pattern3 0 0~65535 Halftone Pattern 3
[16-bit data]
749-023 Halftone Pattern4 0 0~65535 Halftone Pattern 4
[16-bit data]
749-024 TR0 Filter Length 0 0~255 TR0 Filter Constant
[VCLK]
749-036 Lattice Pattern dot 2 1~2 the number of dots per line in lattice pattern
Table 7 ROS
Chain-Link Name Default Range Description
Table 8 Xero/Clean
Chain-Link Name Default Range Description
751-284 DRUM MAX IMPRESSION 78 0~255 Max. number of prints [1000pv]: Drum is available until a max number of prints are made.
Table 9 Process Control
Chain-Link Name Default Range Description
752-010 Flag NewPR 0 0~1 0: old 1: new
752-011 Flag TonerExchange[Y] 0 0~1 0: no replacement 1: replace
752-012 Flag TonerExchange[M] 0 0~1 0: no replacement 2: replace
752-013 Flag TonerExchange[C] 0 0~1 0: no replacement 3: replace
752-014 Flag TonerExchange[K] 0 0~1 0: no replacement 4: replace
752-015 Flag NewToner[Y] 0 0~1 0: old 1: new
752-016 Flag NewToner[M] 0 0~1 0: old 2: new
752-017 Flag NewToner[C] 0 0~1 0: old 3: new
752-018 Flag NewToner[K] 0 0~1 0: old 4: new
752-019 Flag NewIBT 0 0~1 0: old 1: new
752-020 Flag NewIBTcleaner 0 0~1 0: old 1: new
752-040 Temp 0 -100~100 Temperature after AD conversion (NVM100: 0 degree C)
752-041 Humidity 0 0~100 Humidity after AD conversion (NVM0: 0%)
