Xerox WorkCentre 7132

January 2007
6-64
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
752-060 Fail Environment SNR Humidity 0 0~1 Humidity Sensor fail (“Standard Humidity” fixed)
752-061 Fail Environment SNR TEMP 0 0~1 Temperature Sensor fail (“Standard Temp” fixed)
752-091 Judge Number of ADC Fails Mcstop[N] 50 0~255 Threshold used to judge MC should be forcedly stopped in response to”the number of a series of ADC
Fails.” In normal mode
752-092 Judge Number of ADC Fails Mcstop[PN] 8 0~255 Threshold used to judge MC should be forcedly stopped in response to”the number of a series of ADC
Fails.” “Flag Status: Empty Detection”>=1
752-093 Judge Number of ADC Fails Display 3 0~255 Threshold used to judge Fail should be displayed in response to “the number of a series of ADC Fails”
752-094 Fail ADC 0 0~1 ADC Sensor Fail. This fail occurs if a specified or larger number of ADC-related fails occur.
752-095 Fail ADC Sensor 0 0~1 ADC Sensor Fail
752-096 Fail ADC ShutterOpen 0 0~1 Fail: ADC Shutter stays open
752-097 Fail ADC ShutterClose 0 0~1 Fail: ADC Shutter stays closed
752-098 Fail ADC TCpatch[Y] 0 0~1 TC Patch Fail
752-099 Fail ADC TCpatch[M] 0 0~1 TC Patch Fail
752-100 Fail ADC TCpatch[C] 0 0~1 TC Patch Fail
752-101 Fail ADC TCpatch[K] 0 0~1 TC Patch Fail
752-102 Fail ADC patch[Y] 0 0~1 Tone Patch Fail
752-103 Fail ADC patch[M] 0 0~1 Tone Patch Fail
752-104 Fail ADC patch[C] 0 0~1 Tone Patch Fail
752-105 Fail ADC patch[K] 0 0~1 Tone Patch Fail
752-106 Fail ADC LongSetup[Y] 0 0~1 Patch Density Fail during Long Setup
752-107 Fail ADC LongSetup[M] 0 0~1 Patch Density Fail during Long Setup
752-108 Fail ADC LongSetup[C] 0 0~1 Patch Density Fail during Long Setup
752-109 Fail ADC LongSetup[K] 0 0~1 Patch Density Fail during Long Setup
752-111 Flag ADC Dirt 0 0~1 Flag indicating ADC Sensor Detection Surface is contaminated.
752-112 Vcln 760 0~1023 ADC average detection value of Belt-reflected light with Spectral LED On
752-113 Vdatk 0 0~1023 Detection value with both Spectral and Diffuse LEDs Off when Shutter closed.
752-114 DiffusionVcln 30 0~1023 ADC average detection value of Belt-reflected light with Diffuse LED On
752-115 Vref 800 0~1023 Detection value with only Diffuse LED On when Shutter closed.
752-116 Vclose 0 0~1023 Detection value with only Spectral LED On when Shutter closed.
752-121 Number of Continuous ADC Fails 0 0~255 the number of a series of ADC Fails
752-127 VTCpatch[Y] 0 0~1023 TC Patch Vp average value
752-128 VTCpatch[M] 0 0~1023 TC Patch Vp average value
752-129 VTCpatch[C] 0 0~1023 TC Patch Vp average value
752-130 VTCpatch[K] 0 0~1023 TC Patch Vp average value
752-132 Vpatch[Y][B] 0 0~1023 CinB Patch ADC average detection value
752-135 Vpatch[M][B] 0 0~1023 CinB Patch ADC average detection value
752-138 Vpatch[C][B] 0 0~1023 CinB Patch ADC average detection value
752-141 Vpatch[K][B] 0 0~1023 CinB Patch ADC average detection value
752-183 Nominal RADC Target[Y] 432 0~1023 RADC target value set up as the center
752-184 Nominal RADC Target[M] 422 0~1023 RADC target value set up as the center
752-185 Nominal RADC Target[C] 417 0~1023 RADC target value set up as the center
Table 9 Process Control
Chain-Link Name Default Range Description
